2, Product parameters
Sensor type
Electric field (E)

frequency range
50MHz to 3.5 GHz
Directional characteristic
Isosquareness, 3-axis
Measurement range (continuous wave signal>50MHz)
38mV/m to 11V/m
Absolute error (@ 1V/m and 50MHz)
± 1.0dB
Frequency response (correction factor CAL included)
± 1.0dB (50MHz to 1.9 GHz), ± 2.4dB (1.9GHz to 35GHz)
Equisquare deviation
Approximately ± 1.0dB at f>50 MHz
Continuous wave overload limit (CW)
4.2W/m2 (40 V/m)
Temperature effect (0 to 50 ℃)
± 1.5dB
annotation
Unless otherwise specified, all specifications are subject to the following conditions:
Sine wave signal; The device is located in the far field of the emission source, with the sensing rod head pointing towards the emission source; Surrounding temperature+23 ℃± 3 ℃; Relative air humidity 25% to 75%
